FlashLogic FLRSGM7 - Page 10

U.S. Patent No. 8,856,780
TYPE 2 - WIRE CHART - 2 OF 2
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
GMC
Yukon
STD Key
with OnStar
AT
15-16
Parking Light X1 White 26 pin 22 LtGreen/Gray (-) BCM, left side of steering column ~
SWC ~ ~ 16 pin 01 Green (DATA) OBDII connector ~
Ignition ~ Green 06 pin 02 Purple/Black (+) Ignition connector ~
Accessory ~ Green 06 pin 03 Purple/Yellow (+) Ignition connector ~
12V ~ Green 06 pin 04 Red/Blue (+) Ignition connector ~
Mux ~ Green 06 pin 05 White/Purple (MUX) Ignition connector ~
www.flashlogic.comAutomotive Data Solutions Inc. © 2017 FLCGMRSGM7FLRSGM7EN
PAGE 10 OF 26
• 20170705
DOC.: #40640
