FlashLogic FLRSGM7 - Page 15

U.S. Patent No. 8,856,780
TYPE 4 - WIRE CHART - 1 OF 1
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
CHEVROLET
Colorado STD Key
with OnStar
AT
15-16
Parking Light X1 White 26 pin 22 Green/Gray (-) BCM, left side of steering column ~
SWC ~ ~ 16 pin 01 Green (DATA) OBDII connector ~
Lock X2 Blue 27 pin 19 Brown/Yellow (-) BCM, left side of steering column ~
Unlock X2 Blue 27 pin 15
Brown/White (-) BCM, left side of steering column ~
GMC
Canyon STD Key
with OnStar
AT
15-16
Parking Light X1 White 26 pin 22 Green/Gray (-) BCM, left side of steering column ~
SWC ~ ~ 16 pin 01 Green (DATA) OBDII connector ~
Lock X2 Blue 27 pin 19 Brown/Yellow (-) BCM, left side of steering column ~
Unlock X2 Blue 27 pin 15 Brown/White (-) BCM, left side of steering column ~
