Adjusting the legs (*optional)
If your refrigerator is unbalanced:
You can balance your refrigerator by turning the legs of it as illustrated in the figure. The corner where the leg
exists is lowered when you turn in the direction of black arrow and raised when you turn in the opposite
direction. Taking help from someone to slightly lift the refrigerator will facilitate this process.
*
If the subject parts are not included in the product you have purchased, then it is valid for other models.
The backwall of the wooden cabinet must be left open completely to kitchen wall in order to allow sufficient air
circulation to cool down the condenser unit for energy efficiency.
1775
1781
855
32
71
540
545
40
775
1781
1784-1788
855
555
No wooden
back wall
14
