Adjusting the legs (*optional)
If your refrigerator is unbalanced:
You can balance your refrigerator by turning the legs of it as illustrated in the figure. The corner where the leg exists is
lowered when you turn in the direction of black arrow and raised when you turn in the opposite direction. Taking help from
someone to slightly lift the refrigerator will facilitate this process.
* If the subject parts are not included in the product you have purchased, then it is valid for other models.
The backwall of the wooden cabinet must be left open completely to kitchen wall in order to
allow sufficient air circulation to cool down the condenser unit for energy efficiency.
100
100
60
60
1781
1775
1001
32
71
540
545
40
629
1781
1784-1788
1001
555
No wooden
Backwall
