On The Road
04-8
WEIGHING YOUR MOTOR HOME
To Obtain Individual Wheel Positions Weights:
One Side
Scale Weight _____________ lbs.
(Step 1S)
Calculate Other _____________ lbs.
Side Weight (Step 1 - 1S)
Tire Load (lbs.) _____________ lbs.
(See Note*)
Inflation _____________ psi.
(See Note*)
STEP 1S
One Side
Scale Weight _____________ lbs.
(Step 3S)
Calculate Other _____________ lbs.
Side Weight (Step 3 - 3S)
Tire Load (lbs.) _____________ lbs.
(See Note*)
Inflation _____________ psi.
(See Note*)
STEP 3S
*NOTE: Refer to the tire load charts published by the tire manufacturer to determine the
proper inflation pressures recommended for single and dual axles equipped. Always inflate
each axle set to the tire with the higher of the side-to-side loads.
WEIGHING YOUR TANDEM AXLE MOTOR HOME
To Obtain Individual Axle and Gross Vehicle Weights:
Scale Weight _____________ lbs.
(Step 1a = GAW)
From
Owner's Manual _____________ lbs.
GAWR
STEP 1a
Scale Weight _____________ lbs.
(Step 1b = GVW)
From
Owner's Manual _____________ lbs.
GVWR
STEP 1b
Scale Weight _____________ lbs.
(Step 1c)
STEP 1c
Scale Weight _____________ lbs.
(Step 1d = GAW)
From
Owner's Manual _____________ lbs.
GAWR
STEP 1d
Scale Weight _____________ lbs.
Drive Axle GAW = (1c –1d)
From
Owner's Manual _____________ lbs.
GAWR
STEP 1e
(Calculated)
If pulling a towed vehicle, see "Weighing Your Motor Home," Step 4.
