Electrical Systems
Because the inverter uses 12-volt power, extended
use of any available appliance (TV, microwave,
etc.) can run the batteries down. A low power
indicator and automatic shut-down system built
into the inverter can help prevent deep battery
discharge. When the inverter shuts down, the bat-
teries will require recharging through the con-
verter when the motor home is plugged into
external AC service or when operating the gener-
ator. The batteries will also be recharged by the
chassis charging system while on the road.
Ground Fault Circuit Interrupter
(GFCI)
Bathroom, galley, and patio 120-volt electrical
outlets are protected by a Ground Fault Circuit
Interrupter (GFCI). This device is intended to
protect you against the hazards of electrical
shocks possible when using electrical appliances
in the bathroom or galley or in damp areas.
Should a circuit or appliance (electric shaver,
hair dryer, etc.) develop a potential shock hazard,
the GFCI device is designed to disconnect the
outlet (and other outlets on the same circuit),
limiting your exposure time.
Test the GFCI at least once a month. To test
the GFCI:
1. Connect the main power cord to 120-volt AC.
2. Push the TEST button. The RESET button
should pop out, indicating that the pro-
tected circuit has been disconnected.
3. If the RESET button does not pop out when
the test button is pushed, a loss of ground
fault protection is indicated. Do not use any
electrical outlets. Have the motor home
electrical system checked at an authorized
Fleetwood RV Service Center or by a quali-
fied electrician. Do not use the system until
the problem has been corrected.
4. To restore power push the RESET button.
Generator (If Equipped)
Your motor home is equipped with a diesel
powered generator which will provide complete
electrical self-containment when regular public
utility AC power is unavailable. Controls are on
the instrument panel, rear bedroom nightstand
and on the generator.
With the generator operating, power is available
at all of the 120-volt power outlets in the motor
home, just as if the power cord were connected
to an external source. The generator is also con-
nected to the power converter, thus supplying
12-volt power as well. The generator circuit
breakers are located on the generator.
Generator Fuel Supply
Fuel for the generator is taken from the main fuel
tank through a special fuel tube which is higher in
the tank than the fuel tube to the motor home
engine. This arrangement prevents the generator
from running the motor home fuel tank dry.
Generator Operations
To start the generator:
1. Push the control switch to its START posi-
tion and hold it there while the status indi-
cator light blinks rapidly indicating
NOTE
If an outlet doesnʼt work, check the GFCI. Reset it if nec-
essary. If the GFCI continues to trip, have the motor home
electrical system checked at an authorized Fleetwood RV
Service Center or by a qualified electrician.
WARNING
Do not install 12-volt fuses or 120-volt breakers with
amperage ratings greater than that specified on the
device or label. Doing so constitutes a fire hazard.
!
WARNING
Do not under any circumstances operate the genera-
tor while sleeping. You would not be able to monitor
outside conditions to assure that generator exhaust
does not enter the interior, and you would not be alert
to exhaust odors or symptoms of carbon monoxide
poisoning.
!
07-5
