Figure 1Figure 1

Figure 1)

OPERATIONOPERATION

OPERATION

LOADING POINTSLOADING POINTS

LOADING POINTS

Figure 1Figure 1

Figure 1

WARNINGWARNING

WARNING

Wear safety

glasses when

using this tool

1. Pull the

FOLLOWER KNOBS (A)FOLLOWER KNOBS (A)

FOLLOWER KNOBS (A) up

and rotate to the locked position.

2. Insert a stack of FlexiPoints

(B) (B)

(B) (176

points per stack) in the

MAGAZINEMAGAZINE

MAGAZINE

with the notch to the right and release

the

FOLLOWER KNOBFOLLOWER KNOB

FOLLOWER KNOB so it will apply

pressure to the points.

3. Reload a stack of points when the

FOLLOWER KNOBFOLLOWER KNOB

FOLLOWER KNOB reaches the

reload position.

4. The Fletcher FlexiMaster points are

available in boxes of 3,700, order no.

08-955, or 10,000, order no. 08-965.

USING THE FLEXIMASTERUSING THE FLEXIMASTER

USING THE FLEXIMASTER

1. Back up the wood frame with a solid object to absorb the shock and assure

maximum penetration. Place the FlexiMaster on the backing and hold it tight

against the wood as you pull the trigger.

2. After inserting enough points to hold the glass, artwork, mat and

backing, turn the frame right side up for inspection.

3. If it is necessary to clean the glass again, bend the Flexi-Points up, remove the

glass, clean and replace it. Then bend the points back down.

4. The depth of penetration of the point can be adjusted by turning the

ADJUST-ADJUST-

ADJUST-

ABLE KNOB (D)ABLE KNOB (D)

ABLE KNOB (D). Clockwise increases depth, counterclockwise decreases

depth.

CAUTION:CAUTION:

CAUTION: Do not operate the FlexiMaster while pointed at any object other

than the frame. Points can inflict injury.

(C)(C)

(C)
