INTRODUCTION
MachineDimensionsTransportPositionFieldPosition
BoomWidth
Length(1)BoomWidth(2)FoldArmWidth(3)MachineWidth(4)
15.24m13.23m2.9m3.0m15.70m
50ft43ft5in9ft6in9ft10in51ft4in
16.46m13.71m2.9m3.0m16.66m
54ft45ft1in9ft6in9ft10in54ft8in
18.29m14.76m2.9m3.0m18.69m
60ft48ft6in9ft6in9ft10in61ft4in
19.51m15.27m2.9m3.0m19.71m
64ft50ft1in9ft6in9ft10in64ft8in
21.34m16.28m2.9m3.0m21.74m
70ft53ft5in9ft6in9ft10in71ftin
24.38m17.81m3.05m3.4m24.79m
80ft58ft5in10ft0in11ft2in81ft4in
25.60m18.31m3.05m3.4m25.81m
84ft60ft1in10ft0in11ft2in84ft8in
27.43m19.33m3.05m3.4m27.84m
90ft63ft5in10ft0in11ft2in91ft4in
28.65m19.84m3.05m3.4m28.85m
94ft64ft1in10ft0in11ft2in94ft8in
30.48m20.85m3.05m3.4m30.89m
100ft68ft5in10ft0in11ft2in101ft4in
31.70m21.36m3.05m3.4m31.9m
104ft70ft1in10ft0in11ft2in104ft8in
33.53m22.38m3.05m3.4m33.93m
110ft73ft5in10ft0in11ft2in111ft4in
34.75m22.89m3.05m3.4m34.95m
114ft75ft1in10ft0in11ft2in114ft8in
36.58m23.90m3.05m3.4m36.98m
120ft78ft5in10ft0in11ft2in121ft4in
37.80m24.40m3.05m3.4m38.00m
124ft80ft1in10ft0in11ft2in124ft8in
39.62m25.43m3.05m3.4m40.03m
130ft83.5ftin10ft0in11ft2in131ft4in
40.84m25.93m3.05m3.4m46.13m
134ft85ft1in10ft0in11ft2in134ft8in
704002C12
TypicalMachineDimension-WheeledBoomSideView
SQ-044V1212/10/2004
34
