INTRODUCTION
MACHINEDIMENSIONMEASUREMENT
HitchRange(5)36-53cm( 14-21in)
AxletoHitchPin(7)461.0cm( 1811 /2in)
Clearance(6)38.4cm(15.1in)
FieldLength(8)7.06m(23ft2in)
SprayRangeField(9)38.1-119.4cm(15-47in)
MachineHeight(10)2.7m(8ft6in)
SQ-044V1212/10/2004
