Kitchen hood:
Wipe the volume hood with a damp cloth and detergent.
Dismount the filter (see figs. 4 and 5) and place it in hot
water with washing-up liquid. The filter cassette can also be
washed in the dishwasher. Several times a year the volume
hood should be cleaned internally. Wipe it internally with a
damp cloth and detergent. Replace the filter cassette and
press it up so that it fixes to the snap locks.
Fig. 5
Fig. 4
Fig. 6
To change the fluorescent tube, remove the lamp glass
by pressing the snap locks in the direction of the arrow,
Fig. 6.
The fluorescent tube can now be accessed for
replacement.
International
ILCOS code
Philips
designation
Osram
designation
Light
source
FSD-11-G23 PL-S 2-pin DULUX-S
Power 11W 11W 11W
Earth G23 G23 2-pin G23 2-pin
The filter must be cleaned roughly twice a
month with normal use.
The risk of fire increases if the volume hood is
not cleaned as often as specified.
