FLEXSTEEL Sectional - Page 2

A. Back
1 piece
B. Seat
1 piece
F. Y-splitter
1 piece
A. Back
1 piece
B. Seat
1 piece
C.
Transformer
1 piece
STEP 1
STEP 2
Figure 2
Part List for Power Recliner Right/Left Arm
Remove the pack of Wooden Leg (C) of Chaise from the blue spring. Screw in the 4 wooden legs of Chaise
with Washer (C) by turning Wooden legs (C). (See Figure 1)
Figure 1
Flip over the Seat (B) of Chaise / Recliner Right / Left Arm / Console / Armless Recliner, and detach the
transformers (C) and Y-Splitter (F). (See Figure 2) Return the Seat (B) to its upright position. To avoid damage
to the cable, make sure it is clear of the metal base.
Part List for Armless Recliner
Assembly Instructions 2/5
