EN-USEN-US English
A14 Hand strap.
Rear view
Front view
A1 Touch screen LCD.
A2 Cover for the SD memory card slot.
A3 Zoom button.
B1 Laser pointer button: Push to acti-
A4 Stylus pen. Note: Push down the
vate the laser pointer.
stylus pen firmly into its holder when
B2 Preview/Save button: Push and hold
not in use.
down the Preview/Save button for
A5 Camera button: Switch between the
more than 1 second to save an
infrared camera and the digital cam-
image. Push briefly to preview an
era.
image and link additional anno-
A6 Joystick: Move up/down or left/right
tations to the image.
to navigate on menus, in dialog
B3 Focus button: Move left/right to
boxes, and in the image archive.
manually focus the camera. Push to
Push to confirm choices.
autofocus the camera.
A7 A/M button: Push to switch between
B4 Attachment point for the neck strap.
automatic and manual adjustment
B5 Video lamp.
modes. Push and hold down for
B6 Digital camera lens.
more than 1 second to perform a
B7 Release button for additional infra-
non-uniformity correction.
red lenses.
A8 Measure button: Push to dis-
B8 Laser pointer.
play/hide measurement tools.
B9 Infrared lens.
A9 Info button: Push to display/hide
B10 Lens cap for the infrared lens.
image information on the screen.
A10 Setup button: Push to display/hide
the setup menu.
A11 Archive button: Push to open/close
the image gallery.
A12 Mode button: Push to display/hide
the mode selector.
A13 On/Off button: Push to turn on/turn
off the camera.
© 2011, FLIR Systems, Inc. All rights reserved worldwide.
19
Publ. no. 1558790, rev. 008
