FLIR K1 User Manual

Programming Menu
6
2. Flashlight settings: You can set the default intensity for the HIGH and
LOW flashlight. Press MENU at the Flashlight settings option and then
press MENU at the HIGH or LOW option. Then use the arrows to select
the desired default intensity in percent (%).
3. Auto Power OFF (APO): Use the arrows to scroll and MENU to select the
desired APO time (5/15/30 minutes). Set to ‘NEVER’ to disable APO.
• GENERAL SETTINGS
1. Temperature Unit: Use the arrows and the MENU button to select °C or °F.
#NAS100007; r. AA/59809/59809; en-US
15

FLIR K1 Specifications

General

Resolution	160 x 120 pixels
Thermal Sensitivity	<70 mK
Drop Test	2 m (6.6 ft)
Image Frequency	9 Hz
Battery Type	Rechargeable Li-ion
Field of View	57° x 44°
Temperature Range	-4 °F to 752 °F (-20 °C to 400 °C)
Battery Life	5 hours
Focus	Fixed
Display	2.4-inch LCD
Image Modes	Thermal
