FLIR K2 Manual

FLIR K2
P/N: 73701-0101
© 2015, FLIR Systems, Inc.
#73701-0101; r. /26407; en-US
Imaging and optical data
Field of view (FOV)
47° × 31.5°
Depth of field 0.1 m (0.33 ft.), infinity
Focal length 1.9 mm (0.075 in.)
Spatial resolution (IFOV)
6.22 mrad
F-number 1.1
Image frequency 9 Hz
Focus Fixed
Detector data
Detector type Focal plane array, uncooled
microbolometer
Spectral range
7.5–13 µm
Pitch 12 μm
Visual camera
Built-in digital camera 640 × 480 pixels
Digital camera, FOV
73° × 61°, adapts to the IR lens
Sensitivity
Minimum 10 lux
Image presentation
Display
3 in. LCD, 320 × 240 pixels, backlit
Auto range Auto, non-selectable
Image presentation modes
Image modes
• TI Basic fire-fighting mode (default)
• Black-and-white fire-fighting mode
• Fire mode
• Search-and-rescue mode
• Heat detection mode
NOTE
The image mode can only be changed using
FLIR Tools.
Multi Spectral Dynamic Imaging (MSX)
Yes
Measurement
Object temperature range
• –20°C to +150°C (–4°F to +302°F)
• 0°C to +500°C (+32°F to +932°F)
Accuracy
±4°C (±7.2°F) or ±4% for ambient
temperatures of 10–35°C (50–95°F)
2 (9)
www.flir.com
Shop for FLIR products online at:
1.877.766.5412
w ww.ShopThermography.c a

FLIR K2 Specifications

General

Image Frequency	9 Hz
Frame Rate	9 Hz
Focus	Fixed
Video Recording	Yes
IP Rating	IP67
Drop Test	2 m (6.6 ft)
IR Resolution	320 x 240 pixels
Thermal Sensitivity	<100 mK
Thermal Sensitivity/NETD	<100 mK
Spectral Range	7.5 - 13 µm
Battery Type	Li-Ion
Battery Life	4 hours
Battery Operating Time	4 hours
Weight	0.7 kg
Object Temperature Range	-20°C to +350°C (-4°F to +662°F)
