FLIR Ranger R2 Installation And Maintenance Manual

910-0001-00-INS -R02 Page 30 of 53
Information contained in this document pertains to a Canadian origin product that is controlled as "dual use" by the Canadian government. However, when in
the United States or possessed by a US person, it may be considered a defense article from the US Government's perspective. US government authorization
may be required for re-transfer to a foreign person. If you have any questions, please contact FLIR's Global Trade Compliance group at
exportquestions@flir.com .
4.2.1 Typical detection distances — R1, R2 and R3
Detection Ran
ge
R1, R2,
R3
and R3D FastScan
(meter
s
)
Minimum / maximum (Low Crawler)
Minimum / maximum (Walker)
Minimum / maximum (Car)
Note: The R1 is limited to 700m and the R2 to 1400m
Radar Height -5° tilt
-3° tilt -1° tilt 0° tilt 1° tilt
0.5 m
5 / 300
5 / 1100
5 / 2550
5 / 4
00
5 / 1500
5 / 2600
5 / 48
0
5 / 1900
5 / 2600
6 / 5
00
5 / 1900
5 / 2600
9 / 5
00
5 / 1900
5 / 2600
1.0 m
6
/ 300
5 / 1100
5 / 2550
8 / 4
00
5 / 1500
5 / 2600
12 / 48
0
5 / 1900
5 / 2600
16 / 5
00
5 / 1900
5 / 2600
23 / 5
00
5 / 1900
5 / 2600
1.5 m
9
/ 300
5 / 1100
5 / 2550
13 / 4
00
5 / 1500
5 / 2600
19 / 48
0
5 / 1900
5 / 2600
25 / 5
00
5 / 1900
5 / 2600
38 / 5
00
5 / 1900
5 / 2600
2.0 m
13
/ 300
5 / 1100
5 / 2550
17 / 4
00
5 / 1500
5 / 2600
26 / 48
0
7 / 1900
7 / 2600
35 / 5
00
10 / 1900
10 / 2600
5
2 / 5
00
14 / 1900
14 / 2600
2.5 m
17
/ 300
7 / 1100
7 / 2550
22 / 4
00
10 / 1500
10 / 2600
33 / 48
0
14 / 1900
14 / 2600
44 / 5
00
19 / 1900
19 / 2600
66 / 5
00
29 / 1900
29 / 2600
3.0 m
20
/ 300
11 / 1100
11 / 2550
27 / 4
00
14 / 1500
14 / 2600
40 / 48
0
21 / 1900
21 / 2600
54 / 5
00
29 / 1900
29 / 2600
81 / 5
00
43 / 1900
43 / 2600
4.0 m
27
/ 300
18 / 1100
18 / 2550
36 / 4
00
24 / 1500
24 / 2600
55 / 48
0
36 / 1900
36 / 2600
73 / 5
00
48 / 1900
48 / 2600
109 / 5
00
72 / 1900
72 / 2600
5.0 m
34
/ 300
25 / 1100
25 / 2550
46 / 4
00
33 / 1500
33 / 2600
69 / 48
0
50 / 1900
50 / 2600
92 / 5
00
67 / 1900
67 / 2600
138
/ 5
00
100 / 1900
100 / 2600
Table 3 - R1, R2 and R3 Minimum/Maximum Detection Range for Low Crawler, Walker and Car
