QUICK START
INSTRUCTIONS
R
BRAKE FLUSH MACHINE
DISCONNECT
ADD FLUID
COMPLETION
DRAIN THE WASTE TANK
REMOVE FLUID
Close the bleeder valves. Hold the “REMOVE FLUID” button down
until all 4 wheel lights come on. Remove the suction lines from the
vehicle and return them to the machine. Press “STOP”.
Lower the vehicle.
To add uid, connect the wand adapter to the supply line and
press “ADD FLUID”. Place wand into reservoir and open the ball
valve slowly to add the appropriate amount. When nished, close
the ball valve and press “STOP”.
Replace the master cylinder cap and step on the brake pedal to
assure rmness.
To drain the waste tank, connect the wand adapter to the end of
the black hose. Place in an appropriate waste container, open ball
valve, and press “DRAIN WASTE TANK”.
If you need to remove uid, connect the wand adapter to the ABS
line and place wand into reservoir. Press “REMOVE FLUID” and drain
to the appropriate level. When nished, press “STOP”.
Close the ball valve on the yellow hose. While holding a rag around
the connection, disconnect the supply line from adapter. Remove
the adapter. Check the uid level.
