P2
P8 P9
P11 P12 P13 P14
P15
P7
P16 P17 P18 P19
P5 P6
P1
P4
P3
P10
PART DESCRIPTION QTY. PART NUMBER
P1 Main Beam 1 11093003
P2 Secondary Beam 1 11101016
P3 Holder 1 11220005
P4 Front Mount 1 11111018
P5 Right Fixed Pulley 2 11141011
P6 Left Fixed Pulley 1 11151011
P7 Rope 6 x 8000 mm 3 10300002, 11310002 , 11320002
P8 Moveable Pulley 3 10721009
P9 Sling 200 mm 3 10800001
P10 Sling 135 mm 2 10810001
P11 Right Anchor Clip 1 11160001
P12 Left Anchor Clip 1 11170001
P13 Beam End Cap 2 11180001
P14 Masking Tape 1 10960001
P15 Plastic Anchor 6 10970001
P16 Wood Screw 5 x 60 mm 6 11610005
P17 Machine Screw M6 x 50 mm 2 11240001
P18 Machine Screw M6 x 70 mm 2 11250001
P19 Nylock Nut M6 4 11260001
