FLORABEST FGH 700 - Functional Description

7
GB IE CY
plugging it from the mains.
• Makesurethatthemainsvoltagematch-
es the data on the tool’s rating label.
• Ifpossible,connectthetooltoasocket
with a residual-current (RC) trip switch at a
triggering current of not more than 30 mA.
• Avoidskincontactwithearthedobjects
such as metal fences and posts.
• Makesurethattheconnectorontheex-
tension cable is protected from splash
water,andismadeofrubberorhasarub-
ber covering. Only use extension cables
that are intended for outdoor use and are
labelled as such. Use extension cables
with a cable core diameter of at least one
square millimetre. Always completely un-
wind the cable reel before use. Check the
cable for damage.
• Usethecablehangerttedforthepur-
pose when using an extension cable.
• Donotcarrythetoolbythecable.Donot
unplug the cable by tugging on it. Keep
thecableawayfromheat,oilandsharp
edges.
Functional description
Your hand-operated garden tiller is equipped
with a maintenance free electric motor and a
gearbox with sump lubrication.
Thetoolisttedwithfourrotatingtinewheels
that automatically dig themselves into the
ground.
The aluminium frame can be folded to aid
storage.
Please refer to the following descriptions for
the function of the controls.
The major functional parts are
shown on the foldout pages.
Functional parts
A
1a Right-hand fork grip with dead-man
lever,safetyreleasecatchandcable
tension relief
1b Left-hand fork grip
 2 Mainscable
3 Plastic cross-plate
4 Wing-nuts and bolts for securing the
grips
5 Frame tubing
6a Large cable clip
6b Small cable clip
7 Vent
 8 Motorhousing
9 Gearbox
10 Driveshaft
11 Tines
12 Belt clip
Intended purpose
The tool is intended for breaking up and tilling
coarse soil for the purpose of mixing in ferti-
liser,peatandcompostindomesticareas.
Anyuseotherthanthatspecicallynamedin
this manual may lead to damage to the tool
and represents a serious injury hazard for the
operator.
The operator or user of the tool is responsible
for any damage or injury caused to other per-
sons or property.
This tool is intended for use by adults. Chil-
dren and persons unfamiliar with the manual
must not be allowed to use the tool. Do not
use the tool in rain or damp surroundings.
The manufacturer shall not be held liable for
damage arising from improper use or incor-
rect operation of the tool.
