Flotrol F60 - Timer Assembly Parts List

Page 11
Timer Assembly (For Mechanical Meter)
MODEL F60
Item No. Quantity Part No. Description
1 1 051-00078-00 Timer Housing
2 1 069-00188-00 Decal- Instructions2
3 1 057-00011-00 Cycle Actuator Gear- SM
4 1 051-00089-00 Knob
5 4 066-00002-00 Screw,tchw,NO.6-20x1/2,b,black,Zn,1022
6 2 069-00179-00 Button Decal
7 1 069-00186-00 Gallons Label
8 2 066-00008-00 Screw-PSWA
9 1 057-00012-00 Progran Skipper Wheel
10 1 051-00049-00 Dial
11
1 069-00043-00 Quantity Label-40ton
1 069-00184-00 Quantity Label-200ton
1 069-00185-00 Quantity Label-375ton
1 069-01125-00 Quantity Label-1200ton
12 1 051-00050-00 Retainer-PSWA
13 1 051-00068-00 Program Wheel Retainer
14 1 066-00026-00 Screw,tcc,NO.6-20x1/2,JIS SUS304
15 1 069-00181-00 Decal- Time of Day
16 1 052-00013-00 Spring Clip
17 1 057-00024-00 Main Drive Gear(SM)
18 1 099-00192-00 Program Wheel(SM) Assembly
19 1 057-00016-00 Idler Pinion
20 1 058-00007-00 Spring- Idler
21 1 057-00014-00 Idler Gear
22 1 057-00013-00 Driver Gear
23 1 052-00046-00 Motor Mounting Plate
24 1 053-00022-00 Motor2 Assembly（220V/50HZ（
25 3 066-00010-00 Screw,ccch,NO.6-32x1/8,Zn,1022
26 1 057-00021-00 Drive Pinion- Program Wheel
27 1 051-00085-00 Clutch Drive Pinion
28 1 058-00004-00 Spring
29 1 051-00069-00 Spring Retainer
30 2 066-00011-00 Screw,ccch,NO.6-32UNCx1/4,Zn,1022
31
1 052-00041-00 Hinge Bracket
32
2 066-00012-00 Screw,tchw,NO.8-18x3/8,Zn,1022
33
3 052-00048-00 Insulator- Drive Assembly
34
1 043-00004-00 Switch4
35
1 043-00002-00 Switch2
36
2 066-00055-00 Screw,tcp,NO.M3-24x1.125,b,Zn,1022
Bold faced items are recommended spare parts.
