10) It will be necessary to adapt from your existing headers or manifold downpipes to the Flowmaster H-
pipe assembly. Due to the many different variables in header/manifold down pipe locations, we have included
2 #86084S adapter pipes to aid in the fabrication of the connection between these two areas.
11) Remove temporary support and allow the system to suspend on the hangers.
12) Adjust the position of the pipes and mufflers to provide a satisfactory fit. Be sure to maintain an
adequate clearance around all parts of the system to avoid rattles or damage to heat sensitive components.
Once you’re happy with the fit, tighten the clamps down securely. For a cleaner appearance and more secure
installation, we highly recommend welding all slip-fit connections.
PACKING LIST
Qty Description
Part#
2 Muffler 842548-Z
2 Front Adapter Pipe 86084S
1 Left H-pipe Assy. 86074S
1 Right H-pipe Assy. 86075S
2 Muffler Inlet Pipe 86076S
1 Right Over-axle Pipe 86077S
1 Left Over-axle Pipe 86078S
2 Rear Exit Pipe (R/L) 86079S
2 Side Exit Pipe (R/L) 86080S
2 Turndown Exit Pipe (R/L) 86081S
1 Right Dump Down Exit 86085S
1 Left Dump Down Exit 86086S
1 Parts kit PK733
10 2½" Clamp MC250BS
1 2” Clamp MC200BS
6 Rubber Mount HA572
12 3/8” x 1” Bolt HW208
12 3/8” Nut HW103
4 3/8” Flat Washer HW303
12 3/8” Lock Washer HW309
