409S
®
Stainless Steel
Technical Support (800) 544-4761
Installation diagram for:
SYSTEM #817517
1997-2004 CHEVROLET C5 CORVETTE
5.7L V8 ENGINE
PACKING LIST
Qty Description Part#
1 Right Over-Axle Assembly 16377S
1 Left Over-Axle Assembly 16378S
1 Right Muffler Assembly 8525802-R
1 Left Muffler Assembly 8525802-L
1 Parts Kit PK596
2 2½” Band Clamp MC250BS
2 Gaskets GA109
