STORM 2.5 OPERATION GUIDE
Setting up your sprayer
1. Remove the nuts and bolts,
holsters, and nozzles from the
tank strainer (3). Set aside.
2. Bring the ComfortStraps™ (11)
to the bottom of the tank (2).
Secure the lower strap clips to
the loops at the bottom of the
tank. Next, slide the adjustable
strap through the top tank loop.
Continue by sliding the strap
over and under the buckle tting.
Lightly tug to make sure the strap
is secure. Repeat on other side.
3. Place the top wand holster (4)
at the protruding holster mount
on the tank. While holding the
top holster, place a nut (6) on
the side with the hexagonal slot
and screw the bolt through the
other side until it fastens into
the nut. Repeat for the other
slot and the bottom holster (5).
4. Take the spray gun (10) and attach
it to the threaded tting on the
end of the hose (12). Tighten
the tting to ensure the gasket
properly seals the connection.
5. If spraying with the stainless-
steel spray wand (9), pull back on
the collar of the quick-connect
tting on the spray gun. Insert
the male wand quick-connect
into the female spray gun tting
and push the collar back into its
original position. Nozzles can be
attached with the same process.
6. Snap the spray wand into the wand
holster and place any unused
nozzles into storage slots until
ready to spray.
