A ....... SPYDRx or SPYDRx PLUS console pre-configured with:
B........( 5 ) or ( 8 ) C-brackets
C .......( 10 ) or ( 16 ) Clamping knobs
D........( 5 ) or ( 8 ) Male DC connectors
E .......AUX input for controller (controller sold separately)
F ........Female AC connector
G ....... ( 5 ) or ( 8 ) SPYDR RAY light bars pre-configured with:
H........Slider bracket
I..........Female DC connector
J......... ( 2 ) Gripple wire hanger
K........ ( 1 ) Adjustable kit (option if upgraded at time of purchase)
L......... ( 4 ) Nylon spacers
M....... ( 4 ) Self-tapping screws
N ....... ( 1 ) 6’ AC cable (15’ cable option if upgraded at time of purchase)
O....... Vinyl-cut Fluence sticker
SYSTEM HARDWARE + ACCESSORIES
A
F
D
E
C
B
PRODUCT LEGEND
5
System Hardware
Accessories
G
I
H
O
M
K
L
J
N
ACCESSORIES
