13
(a) Increase/Decrease arrows for setting the chlorine output level of the chlorinator. The chlorinator output can be set
from levels 1 through to 8. This level only applies to Pool Mode. When the Chlorinator is in Spa mode, the chlorine
output will be at level 1.
(b) Chlorine Output display shows the level set.
(c) The LCD display will also show an output level from 1 to 8 which indicates the performance of the chlorinator
compared to the Chlorine Output LED’s. Should the LCD output level (1 to 8) be less than the LED output, check salt
level in pool. Should salt level be at 4000 ppm and output more than 2 settings less than LED display, your cell may
need replacing.
2.4 User Mode
The user mode buttons enable you to select Pool or Spa mode and to manually control the Chlorinator/Pump. Functions are as
follows:
(a) POOL MODE: Sends a message to other Astral equipment (if fitted) to go to Pool mode. There are 3 Pool Modes:
Auto The Chlorinator/Pump will run according to how you have set the timers.
On The Chlorinator/Pump will run continuously.
Standby/Off The Chlorinator/Pump will stay off continuously.
(b) SPA MODE: Sends a message to other Astral equipment (if fitted) to go to Spa mode and turns the pump on.
