fluimac PHOENIX - Page 22

22 Rev. 03
PHOENIX P170/P252/PF170
PHOENIX P170/252 A B C D E H Q S T
Weight
Kg
Min/Max
Temperature
P170 AISI 316 356.5 222 371 129 254 293.5 66 9 46 20 -20°C/95°C
P252 AISI 316 356.5 222 371 129 254 293.5 66 9 46 20 -20°C/95°C
AISI 316 FOOD
TRI
-
CLAMP 1”1/2
356.5 222 371 129 254 293.5 66 9 46 20 -20°C/95°C
