fluimac PHOENIX - Page 23

23 Rev. 03
PHOENIX P170/P252/PF170
POS. CODE MATERIAL DESCRIZIONE DESCRIPTION
Q. for
PUMP
1 P0065CCR04221PP PP Centrale nuova versione Central block new version 1
1 P0065CCR04221PC PC+CF Centrale nuova versione Central block new version 1
1a GUARNORC03075NR NBR O-ring O-ring 1
2 E-065 POM-c Distributore Pneumatic Exchanger 1
3 P0160AL004401A2 AISI Albero Shaft 1
3a GUARNORC02050NR NBR O - ring albero Shaft O-ring 1
4 P0065DF000102PM POM-c Disco intermedio con O-ring Intermediate plate with O-ring 1
5 MOLLA70C25122AC STEEL Molla a tazza Belleville washer 4
6 P0160PT004402AL ALUMINUM Piattello lato aria Air side cap 2
7a P0160ME004248HY Hytrel Membrana lato aria Air diaphragm 2
7a P0160ME004248SA Santoprene Membrana lato aria Air diaphragm 2
7a P0160ME004710DT EPDM Membrana lato aria Air diaphragm 2
7a P0160ME004710NR NBR Membrana lato aria Air diaphragm 2
7b P0160ME004317TF PTFE Membrana lato fluido Fluid diaphragm 2
8 P0160CAR04448A4 AISI 316 Cappellotto lato fluido Fluid side cap 2
9 P0065GR004170PP PP+VTR Griglia silenziatore con O-ring Silencer grid with O-ring 1
10a P0065SL004266FL FELT Silenziatore esterno External silencer 1
10b P0160SL004637FL FELT Silenziatore interno Internal silencer 1
11 P0170CPR00192A4 AISI 316 Corpo pompa Pump casing 2
11 P0170CPR00192A4
AISI 316
POLISHED
Corpo pompa Pump casing 2
12a P0170CLR00193A4 AISI 316 Collettore superiore Upper manifold 2
12b P0170CLR00194A4 AISI 316 Collettore inferiore Lower manifold 2
12a P0252CLR00197A4 AISI 316 Collettore superiore Upper manifold CLAMP 2
12b P0252CLR00198A4 AISI 316 Collettore inferiore Lower manifold CLAMP 2
12a F0170CLR00195A4
AISI 316
POLISHED
Collettore superiore CLAMP Upper manifold CLAMP
12b F0170CLR00196A4
AISI 316
POLISHED
Collettore inferiore CLAMP Lower manifold CLAMP
14 SFERAMMC04000TF PTFE Sfera Ball 4
14 SFERAMMC04000A4 AISI 316 Sfera Ball 4
15 P0170SD000285A2 AISI Sede sfera Ball seat 4
19 VITEM10C16025A2 AISI Viti collettore Manifold screw 8
19a RONDP50C06012A2 AISI Rondelle Washers 8
19b DADOM32C00006A2 AISI Dadi collettori Manifold nuts 8
21 VITEM10C16040A2 AISI Viti corpo pompa Casing screw 20
21a RONDP50C06012A2 AISI Rondelle Washers 20
21b DADOM31C00006A2 AISI Dadi corpo centrale Nuts 20
23 VITEA18C04023A2 AISI Viti griglia silenziatore Silencer grid screw 4
24 VITEA18C04010A2 AISI Vite tapo distributore
Cover
pneumatic exchanger
screw
1
31
GUARNORC004042N
R
NBR O-ring silencer Silencer o-ring 1
32 GUARNORC04188TF PTFE Guarnizione inferiore Lower gasket 4
42 P0065BC000101PM POM-c
Boccola di comando con O
-
ring
nuova vers.
Command bush with o
-
ring
new
version
1
43 SEEGEFOC04717AC STEEL Seeger distributore Pneumatic exchanger seeger 1
44 SEEGEFOC05020AC STEEL Seeger disco intermedio Intermedidiate plate seeger 1
45 P0065TP004703PP PP+VTR Tappo distributore Pneumatic exchanger cover 1
47 P0050DS005375PP PP Distanziale corsa spacer 2
