PHOENIX P700 PLASTIC AND
ALUMINIUM VERSION
POS
.
CODE
MATERIAL
DESCRIZIONE
DESCRIPTION
Q. for PUMP
1 P0700CCR04355PP PP Centrale Central block 1
1
P0700CCR04355PC
PP+CF
Centrale
Central block
1
2
E
-
700
POM
-
c
Distributore
Pneumatic Exchanger
1
3
P0700AL004644A2
AISI 304
Albero
Shaft
1
4
P0700DF004363PM
POM
-
c
Disco
intermedio con O
-
ring
Intermediate plate with O
-
ring
2
5
MOLLA70C40162AC
STEEL
Molla a tazza
Belleville washer
4
6 P0700PT004423AL ALUMINUM Piattello lato aria Air side cap 2
7a
P0700ME004262HY
Hytrel
Membrana lato aria
Air diaphragm
2
7a
P0700ME004262SA
Santoprene
Membrana lato aria
Air diaphragm
2
7a
P0700ME004711DT
EPDM
Membrana lato aria
Air diaphragm
2
7a
P0700ME004711NR
NBR
Membrana lato aria
Air diaphragm
2
7b
P0700ME004475TF
PTFE
Membrana lato fluido
Fluid diaphragm
2
8 P0700CA104422PP PP+VTR Cappellotto lato fluido Fluid side cap 2
8
P0700CA104422FC
PVDF+CF
Cappellotto lato fluido
Fluid side cap
2
8
P0700CA104422PC
PP+CF
Cappellotto lato fluido
Fluid side cap
2
8
P0700CAR04421AL
ALUMINUM
Cappellotto lato fluido
Fluid side cap
2
9
P0700GR004395PP
PP+VTR
Griglia silenziatore
silencer grid
1
10
P0700SL004725FL
FELT
Silenziatore
Silencer
1
11 P0700CP004354PP PP+VTR Corpo pompa Pump casing 2
11
P0700CP004354FC
PVDF+CF
Corpo pompa
Pump casing
2
11
P0700CP004354PC
PP+CF
Corpo pompa
Pump casing
2
11
P0700CP004349AL
ALUMINUM
Corpo pompa
Pump casing
2
12
P0700CLR04352PP
PP+VTR
Collettore superiore/inferiore 2"
Upper/lower manifold
2
12 P0700CLR04352FC PVDF+CF Collettore superiore/inferiore 2" Upper/lower manifold 2
12
P0700CLR04352PC
PP+CF
Collettore superiore/inferiore 2"
Upper/lower manifold
2
12
P0700CLR04350AL
ALUMINUM
Collettore superiore/inferiore 2"
Upper/lower manifold
2
13
P0700GA004362PP
PP +VTR
Gabbia
Ball cage guide
4
13
P0700GA004362EC
ECTFE
Gabbia
Ball cage guide
4
14
SFERAMMC00060TF
PTFE
Sfera
Ball
4
14 SFERAMMC00060A4 AISI 316 Sfera Ball 4
14
SFERAMMC00060DT
EPDM
Sfera
Ball
4
14
SFERAMMC00060NR
NBR
Sfera
Ball
4
15
P0700SD000094FV
PVDF
Sede sfera
Ball seat
4
15
P0700SD000093PP
PP
Sede sfera
Ball seat
4
15
P0700SD004643PZ
UHMW HDPE
Sede sfera
Ball seat
4
15 P0700SD004643AL ALUMINUM Sede sfera Ball seat 4
15
P0700SD004643A2
AISI 304
Sede sfera
Ball seat
4
16
P0700CO004399PP
PP +VTR
Collare
Collar
2
17
P0700PD004400PP
PP +VTR
Piede
Foot
2
19
VITEM20C08110A2
AISI 304
Viti collettore
Manifold s
crew
16
19a
RONDP50C08016A2
AISI 304
Rondelle
Washers
16
21 VITEM10C08140A2 AISI 304 Viti corpo pompa Casing screw 20
21a
RONDP50C08024A2
AISI 304
Rondelle
Washers
20
21b
DADOM31C00008A2
AISI 304
Dadi
Nuts
36
22
VITEA18C04018A2
AISI 304
Viti disco intermedio
Intermediate plate s
crew
8
23
VITEA18C04030A2
AISI 304
Viti griglia silenziatore
Silencer grid s
crew
5
24
VITEA18C04010A2
AISI 304
Vite tapo distributore
Cover pneumatic exchanger s
crew
1
32 GUARNORC06337NR NBR O-ring sup. Upper o-ring 4
32
GUARNORC06337VT
FPM
O
-
ring sup.
Upper o
-
ring
4
32
GUARNORC06337DT
EPDM
O
-
ring sup.
Upper o
-
ring
4
32
P0700GN004833TF
PTFE
Guarnizione sup.
Upper gasket
4
33
GUARNORC06275NR
NBR
O
-
ring inf.
Lower o
-
ring
4
33
GUARNORC06275VT
FPM
O
-
ring inf.
Lower o
-
ring
4
33 P0700GN000088TF PTFE Guarnizione inf. Lower gasket 4
33
GUARNORC06275DT
EPDM
O
-
ring inf.
Lower o
-
ring
4
42
P0700BC004645PM
POM
-
c
Boccola con O
-
ring pattini
Bushing wi
t
h O
-
ring
1
43
SEEGEFOC06525AC
STEEL
Seeger distributore
Pneumatic exchanger s
eeger
1
45
P0065TP004703PP
PP+VTR
Tappo distributore
Pneumatic exchanger c
over
1
45a
P0700AD004740PP
PP
Adattatore tappo distributore
Pneumatic exchanger
adapter cover
1
47 P0700DS000034PP PP Distanziale corsa Spacer stroke 2
48
TUBOAIRC06170PU
Poliuretano
Tubo aria D 6mm
Air tube D 6mm
2
49
RACCO92C00006OT
BRASS
Raccordo a
cartuccia
Fitting cartridge
4
