fluimac PHOENIX - Page 30

30 Rev. 03
PHOENIX P700 PLASTIC AND
ALUMINIUM VERSION
PHOENIX P700 A B C D E H Q S T
Weight
Kg
Min/Max
Temperature
PP 595 345 565 213 399 392 115 12.5 95 31 -4°C/65°C
PVDF+CF 595 345 565 213 399 392 115 12.5 95 36 -20°C/95°C
PC+CF 595 345 565 213 399 392 115 12.5 95 36 -4°C/65°C
ALU 595 345 560 213 399 390 115 12.5 94 36 -20°C/90°C
