fluimac PHOENIX - Page 29

29 Rev. 03
PHOENIX 400 AISI VERSION
POS. CODE MATERIAL DESCRIZIONE DESCRIPTION
Q. for
PUMP
1 P0400CCR00058PP PP Centrale Central block 1
1 P0400CCR00058PC PP+CF Centrale Central block 1
2 P0400CCR00058PPB PP Centrale Central block for food 1
2 E-400 POM-c Distributore Pneumatic Exchanger 1
3 P0400AL000061A2 AISI 304 Albero Shaft 1
3a GUARNORC02050NR NBR O-ring O-ring 1
4 E0400CM000060PM POM-c Diaframma con O-ring Intermediate plate with O-ring 1
4a E0400AN000059PM POM-c
Anello diaframma con O
-
ring
Intermediate plate
ring
with O
-
ring
2
5 MOLLA70C25122AC STEEL Molla a tazza Belleville washer 4
6 P0160PT004402AL ALUMINUM Piattello lato aria Air side cap 2
7a P0400ME000063HY HYTREL Membrana lato aria Air diaphragm 2
7a P0400ME000063SA
SANTOPRE
NE
Membrana lato aria Air diaphragm 2
7b P0400ME000064TF PTFE Membrana lato fluido Fluid diaphragm 2
8 P0160CAR04448A4 AISI Cappellotto lato fluido Fluid side cap 2
9 P0400GR000066PP PP Griglia silenziatore Silencer grid 2
10 P0400SL000202FL Felt Silenziatore Silencer 4
11 P0400CPR00112A4 AISI 316 Corpo pompa Pump casing 2
11 P0400CPR00112A4
AISI 316
POLISHED
Corpo pompa Pump casing 2
12a P0400CLR00114A4 AISI Collettore superiore 1"1/2 Upper manifold 1"1/2 1
12a F0400CLR00117A4
AISI 316
POLISHED
Collettore superiore
CLAMP 2"
Upper manifold CLAMP 2" 1
12b P0400CLR00115A4 AISI Collettore inferiore 1" 1/2 Lower manifold 1"1/2 1
12b F0400CLR00118A4
AISI 316
POLISHED
Collettore inferiore CLAMP
2"
Lower manifold CLAMP 2" 1
14 SFERAMM00045TF PTFE Sfera Ball 4
14 SFERAMM00045A4 AISI Sfera Ball 4
15 P0400SD000116A4 AISI Sede sfera Ball seat 4
19 VITEM10C08040A2 AISI Viti collettore Manifold screw 16
21 VITEM10C08055A2 AISI Viti corpo pompa Casing screw 20
21a RONDP50C08018A2 AISI Rondelle corpo/collettori Casing/manifold washer 36
21b DADOM31C00008A2 AISI Dadi corpi collettori Casing/manifold nuts 36
23 VITEM18C04018A2 AISI Viti griglia silenziatore Silencer grid screw 8
24 VITEM10C04016A2 AISI Viti tappo distributore
Cover pneumatic exchanger
s
crew
4
24a RONDP50C06012A2 AISI rondelle tappo distributore
Cover pneumatic exchanger
w
asher
4
32 GUARNORC00158TF PTFE O-ring sup. Upper o-ring 4
42 P0400BC000199PM POM-c
Boccola di comando con O
-
ring
Bushing with O-ring 1
43 SEEGEFOC05520AC STEEL Seeger distributore Pneumatic exchanger seeger 1
44 SEEGEFOC04017AC STEEL Seeger diaframma Central block seeger 2
45 P0400TP000113PP PP Tappo distributore Pneumatic exchanger cover 1
47 P0400DS000062PM POM-c Distanziale corsa Stroke spacer 2
