Fluke 5220A - Page 106

5 220A
Instruction Manual
5-34
Table 5-11. A10 Logic PCB Assembly
Reference Designator Description
Fluke
Part No.
Total
Quantity
C1, C3, C4
Capacitor, Mica, 100 pF, ±5 %, 500 V
148494 3
C2
Capacitor, TA, 4.7 µF, ±20 %, 25 V
161943 1
C5
Capacitor, TA, 2.2 µF, ±20 %, 20 V
161927 1
C6 – C8
Capacitor, TA, 1 µF, ±10 %, 35 V
161919 3
C9
Capacitor, TA, 22 µF, ±20 %, 15 V
423012 1
C10 – C14
Capacitor, CER, 0.22 µF, ±20 %, 50 V, Z5U
309849 5
C15
Capacitor, CER, 0.01 µF, +80-20 %, 100 V, Z5V
149153 1
C16
Capacitor, TA, 0.47 µF, ±20 %, 35 V
161349 1
CR1 – CR3
h Diode, SI, BV = 75 V, IO = 150 mA, 500 mW
203323 3
R1, R2, R9, R10, R15, R16,
R19
Resistor, CF, 220 Ω, ±5 %, 0.25 W
342626 7
R3 – R6, R8, R11, R12, R14,
R17, R18, R20, R21
Resistor, CF, 10 k, ±5 %, 0.25 W
348839 12
R7, R22
Resistor, CF, 47 k, ±5 %, 0.25 W
348896 2
R13, R24, R26
Resistor, CF, 100 k, ±5 %, 0.25 W
348920 3
R22
Resistor, CF, 10 k, ±5 %, 0.25 W
348839 1
R23, R25
Resistor, CF, 4.7 k, ±5 %, 0.25 W
348821 2
TP1, TP2 Terminal, Un-insulated, Feed-through, Hole,
Turret
179283 2
U1, U4, U5, U20 Isolator, Opto, LED to Transistor, Dual 454330 4
U2
h IC, CMOS, Quad, 2-Input NAND w/Schmitt
Trigger
404632 1
U3
h IC, CMOS, Hex Inverter
404699 1
U6, U19
h IC CMOS, Quad 2-Input AND Gate
408401 2
U7, U10
h IC, CMOS, Dual D F/F, + Edge Trigger
418830 2
U8, U11
h IC, CMOS, Retrigger/Reset Multivibrator
393512 2
U9
h IC, CMOS, Triple 3-Input NOR Gate
355180 1
U12 – U14
h IC, LSTTL, Quad 2-Input NAND Gate
393116 3
U15
h IC, TTL, Dual NAND Driver w/Open Collector
329706 1
U16, U17
h IC, CMOS, Dual D F/F, + Edge Trigger
340117 2
U21
h IC, CMOS, Triple 3-Input OR Gate
408575 1
U22
h IC, LSTTL, 4-Bit Parallel I/O Right and Left
Shift Register
393249 1
U23
h IC, Bipolar, Timer, 8-Pin, DIP
402610 1
XU23 Socket, IC, 8-Pin 478016 1
h Indicates a static-sensitive part.
