5 220A
Instruction Manual
5-36
Table 5-12. A11 MIS Bus Interface PCB Assembly
Reference
Designator Description
Fluke
Part No.
Total
Quantity
C1 Capacitor, TA, 4.7 µF, ±20 %, 25 V 161943 1
C2 Capacitor, TA, 22 µF, ±20 %, 15 V 423012 1
C3, C4 Capacitor, CER, 0.22 µF, ±20 %, 50 V, Z5U 309849 2
CR1 h Diode, SI, BV = 75.0 V, IO = 150 mA, 500 mW 203323 1
H1 Screw, Machine, PH, P, SEMS, Steel, 4-40, 0.250 185918 2
J71 Connector, Micro-Ribbon, REC, PCB, 24 Position 441337 1
MP1 Connector ACC, Micro-Ribbon, Latch 412700 2
MP2 Connector ACC, Micro-Ribbon, Spring 412718 2
MP3 Spacer, Swaged, Round, Brass, 4-40 x 0.187 335604 2
MP4 Spacer, Swaged, Round, Brass, 6-32 x 0.570 261875 1
R1 – R12 Resistor, CF, 10 k, ±5 %, 0.25 W 348839 12
R14 – R22 Resistor, CF, 1 k, ±5 %, 0.25 W 343426 9
R23 Resistor, CF, 47 k, ±5 %, 0.25 W 348896 1
TP1 – TP2 Terminal, Un-insulated, Feed-through, Hole, Turret 179283 2
U1 h IC, CMOS, Quad D F/F, + Edge Trigger, w/Clear 452912 1
U2 – U7 h IC, LSTTL, Quad 2-Input NAND Gate 394205 2
U3 h IC, CMOS, Hex Inverter 404699 1
U4 h IC, CMOS, Quad 2-Input NAND Gate 418509 1
U5 h IC, CMOS, Triple 3-Input NAND Gate 418244 1
U6 h IC, LSTTL, Quad 2-Input NAND Gate 393116 1
h Indicates a static-sensitive part.
To Next Page
