5 220A
Instruction Manual
5-38
Note
The A12 shunt assembly is a suggested non-repairable assembly.
Table 5-13. A12 Shunt Assembly
Reference
Designator Description
Fluke
Part No.
Total
Quantity
H1 Screw, Machine, SEMS, PH, P, Steel, 6-32 x 0.500 177030 4
H2 Screw, Machine, RH, SL, Steel, 6-32 x 2.750 115022 4
H3 Nut, Mini, Hex, SS, 6-32 110569 4
H4 Solder, Tin-Lead Alloy, Preform Ring 516989 32
J1 – J4 Banana Plug, Panel 101543 4
MP1 Top Support, Shunt 489906 1
MP2 Bottom Support, Shunt 489914 1
MP3 Terminal, Shunt 489922 2
MP4 Element, Shunt 524397 16
MP5 Spacer, Round, Aluminum, 0.156 ID x 0.156 157792 4
MP6 Spacer, Round, Aluminum, 0.156 ID x 1.500 104257 4
MP7 Spacer, Round, Aluminum, 0.156 ID x 1.000 102905 4
W1 Cable, Shunt 502674 1
