70/73 English Instruction Sheet
Page
3
Automatic Touch Hold
Mode
W Warning
To avoid electric shock, do not use the Touch Hold
to determine if a circuit with high voltage is dead.
The Touch Hold
mode will not capture unstable or
noisy readings.
The Touch Hold mode automatically captures and displays
stable readings. Press R for 2 seconds while turning the
meter on.
2 seconds
+
_
V DC
V DC
H
_
+
_
V DC
single
beep
V V V
hr3f.eps
When the meter captures a new input, it beeps and a new
reading is displayed. To manually force a new measurement to
be held, press R.
Note
Stray voltages can produce a new reading.
To exit the Touch Hold
mode, turn the meter off.
Bar Graph
The bar graph shows readings relative to the full scale value of a
displayed measurement range and indicates polarity.
hr16f.eps
