6
*1
Instruments with GPIB/IEEE 488.2 or RS232 interface
*2
Zo=50Ω, Rl=50Ω, Modulation off
*3
Via GPIB interface
Model PM 5136 PM 5138A PM 5139
Sweep
Carrier waveform All
Sweep functions Single
Continuous
Hold/Release
Reset to start frequency
Sweep characteristics Linear or logarithmic
Up or down
Sweep modes Sweep and flyback
Sweep and hold
Sweep from f
start
to f
stop
and back to f
start
Sweep ranges max. 1mHz - 5MHz 1mHz - 5MHz 1mHz - 10MHz
50kHz - 10MHz 50kHz - 20MHz
Sweep time 10ms - 1000s
Number of frequency steps Sweep time / 1ms
Gate Non-coherent signal keying
Carrier frequencies All
Carrier waveforms All
Gate, internal
Keying frequency 10Hz – 100kHz
Duty cycle 50%
Gate, external
Keying frequency 0 – 200kHz, TTL signal
Interface bus remote control
Isolation in- and outputs galvanically separated with opto-couplers
Control capability all functions and characteristics
GPIB/IEEE-488.2 Address range 0 - 30 and listen only mode
RS232
Baud rate / data ../ 110-19200 / 7 or 8 / 1 / odd, even or no parity
stop bits
Handshake hardware or software (Xon/Xoff)
Miscellaneous
Instrument settings 1 + 9
Rear connectors modulation input / triggering input / reference input / TTL output /
modulation output / penlift output / sweep output / 10 MHz reference output /
interface bus connector
*1
/ power connector
Dimensions (HxWxD) 105 x 315 x 405 mm
Weight 6.7 kg 6.1 kg 6.7 kg
Operating conditions
Temperature Reference 23°C ± 1°C, Operating + 5 .. +40°C Storage -40 .. +70°C
Safety According to CE regulation 73/23: EN 61010-1, CAT II, Pollution Degree 2
EMC According to CE regulation 89/336:
Emission according to EN 55 011 Group 1 Class B, respectively CISPR 11.
Immunity according to EN 50 082-1, inclusive IEC 801-2, -3, -4.
Power / line frequency 100,120,220,240V / 50 - 60 Hz ± 5%
Power consumption 42W 66W 58W
