Installation Components
Installation Using 1 Amplifi er
Amplifi er
Selector A
1 Amp
Input Jumper Positions
On
Off
On
Off
Selector B
1 Amp
Input Jumper Positions
On
Off
On
Off
Input
Selector A
Input
Selector B
WARNING
Install 2 (two) Amplifi er or more, jumper input must be installed correctly.
Wrong installation on input jumper can damage the Amplifi er
XMC 361
+ -
+ -
+ -
+ -
HT 25 MC
T 160 MC3
M 80 MC
