Flux Reference Series - Page 14

HT 25 MC
T 160 MC3
M 80 MC
Selector A
2 Amp
Input Jumper Positions
On
Off
On
Off
Selector B
2 Amp
Input Jumper Positions
On
Off
On
Off
Input
Selector A
Input
Selector B
WARNING
Install 2 (two) Amplifi er or more, jumper input must be installed correctly.
Wrong installation on input jumper can damage the Amplifi er
Installation Using 2 Amplifi ers
XMC 361
+ -
+ -
+ -
+ -
+ -
Maestro Competition Series [MC Comp 361]
13
Woofer
Amplifi er
Tweeter
Midrange
Amplifi er
