Fuselage
5
Assembly Fan unit
6
Elevator
Throttle
Battery
Optional
Air valve (main gear)
Connect to main
retract gear air cylinder
(Optional)
Aileron
Connect to aileron servo
Optional extension cable required for
the connection of the aileron servo.
2 pcs required
800mm
1. Single cable
(Alieron)
Note : Install the cable and air tube before glue the fuselage together with epoxy.
A
B
(a) Never operate the unit with loose items of clothing or equipment near to the intake area.
(b) Never operate the unit held in your hands as personal injury, or damage to the unit may occur.
(c) Always do a thorough inspection of the unit prior to any operational use.
(d) Always think safety first.
(e) Secure all the screws. If any screws loose while rotating and the serious injury may occur.
Caution : As proper use of the fan unit is out of the influence of the manufacturer, the operation of the fan unit is on
owners risk!
This is not a toy! The unit should only be operated by childs of 12 years and supervised by an adult.
To Next Page
