Fly Fly Hobby FF-D005 - Final Adjustments and Flight Preparation; Control Surface and Dimensional Adjustments; Center of Gravity (CG) Balancing Procedure

Copyright 2009 Fly Fly Hobby
Designed and Manufactured by : Fly Fly Hobby Mfg. http://www.flyflyhobby.com
C
FLYFLY HOBBY
11
Adjustment
12
A
A’
B
B’
A = A’
B = B’
ELEVATOR
AILERON
25 mm
25 mm
25 mm
25 mm
217 mm
Never fly before checking the CG’s required position.
Reposition the receiver and battery to obtain the correct CG’s location.
NEVER fly the model without well balancing.
184 mm
Adjustment
165mm
150mm
217 mm
