Please follow the installation instructions and make sure the
bench is fully installed before you start using it.
ATTENTION!
Unfold the main frame, insert two [M10*95 Bolts] and one [M8*60 Bolt]
separately.
Step one
Install [Front Foot Tube] with two [M10*45 Screws]. Install [Rear Foot
Tube] with four [M8*12 Screws].
Step two
6-M8*60 Bolt
9-M10*95 Bolt
4-Front Foot Tube
8-M10*45 Screw
7-M8*12 Screw
3-Rear Foot Tube
3
