3
Unpack and check contents.
Remove all the items from the box. If any part are missing, contact your place of
purchase at once.
Assembly should be done on a clean, level surface with a helper.
1.
Take
out the body from the box and place it on a wood shelf.
figure 1
2. Attaching the funnel to the basic machine, see figure 2
figure 2
2.1. Place the big funnel on the main body.
