Carton Contents
IMPORTANT ! Please check the contents of the carton are correct BEFORE
assembling your new product.
IF ANY PARTS ARE MISSING CONTACT:-
Husqvarna UK Ltd. Customer Service Department direct
Telephone : 0844 844 4558 UK 1800 882 350 ROI Fax : 01325 302530
Safety
If not used properly this product can be dangerous! This product can cause serious injury to the
operator and others, the warnings and safety instructions must be followed to ensure reasonable
safety and efficiency in using this product. The operator is responsible for following the warning
and safety instructions in this manual and on the product. Never use the product unless the
grassbox or guards provided by the manufacturer are in the correct position.
Explanation of Symbols on your product
Warning
Read the user instructions carefully to
make sure you understand all the controls
and what they do.
Always keep the product on the ground
when using. Tilting or lifting the product
may cause stones to be thrown out.
Keep bystanders away. Do not use whilst
people especially children or pets are in
the raking area.
Beware of sharp tines. Tines continue to
rotate after the motor is switched off -
remove plug from mains before
maintenance or if cable is damaged.
Keep the cable supply away from the
tines.
electric
cable with
moulded
on plug
upper handle
wing knob x 2
lower handle
wing knob x 2
cable
clip x 2
bolt x 2 (M6)
instruction
manual
pack of tines
upper handle
lower handle
start/stop lever
switchbox
deck
lock off
button
collection box
washer
x 2 (M6)
bolt x 2
(M8)
height adjustment
handle
rear wheel x 2
rear wheel hub cap
x 2
front wheel x 2
front wheel hub cap
x 2
