16. Insert top o-ring (40) and ring seal (41) in fluid cylinder counterbore using heavy
oil or grease to hold in place.
17. Return fluid cylinder (38) to position over cylinders (42) and ensure that all seals
are in place.
18. Replace fluid end cap screws (39). Torque cap screws in 3 stages to values
shown in the Fastener Torque Table in Section 10.0 (reference Table 5).
