PARTS
This list contains replaceable parts used in your rebox. When ordering parts, follow the
instructions listed under Replacement Parts on page 23 of this manual.
KEY
NO. PART NO. DESCRIPTION QTY.
1 116084-01 Hearth 36" Natural White • • 1
111426-01 Hearth 42" Natural White • • 1
111428-01 Hearth 50" Natural White • • 1
2 116082-01 Right Stacked 36" Natural White • 1
116087-01 Right Herringbone 36" Natural White • 1
125832-01 Right Stacked 42" Natural White • 1
125835-01 Right Herringbone 42" Natural White • 1
125838-01 Right Stacked 50" Natural White • 1
125841-01 Right Herringbone 50" Natural White • 1
3 116081-01 Left Stacked 36" Natural White • 1
116086-01 Left Herringbone 36" Natural White • 1
125833-01 Left Stacked 42" Natural White • 1
125836-01 Left Herringbone 42" Natural White • 1
125839-01 Left Stacked 50" Natural White • 1
125842-01 Left Herringbone 50" Natural White • 1
4 116083-01 Rear Stacked 36" Natural White • 1
116088-01 Rear Herringbone 36" Natural White • 1
125831-01 Rear Stacked 42" Natural White • 1
125834-01 Rear Herringbone 42" Natural White • 1
125837-01 Rear Stacked 50" Natural White • 1
125840-01 Rear Herringbone 50" Natural White • 1
5 116091-01 Ash Panel 36" Natural White • • 1
111425-01 Ash Panel 42" Natural White • • 1
111430-01 Ash Panel 50" Natural White • • 1
6 110822-01 Corner Refractory Bracket • • • • • • 2
VU36S, Q36S,VQ36S VU36H, Q36H, VQ36H VU42S, Q42S, VQ42S VU50S, Q50S, VQ50S
VU42H, Q42H, VQ42H VU50H, Q50H, VQ50H
