• Product Name: FS-R4A1
• Adaptive transmitter: FS-MG41
• Model Type: Car
• Channels: 4
• Numbers of Light Interfaces: 7
• RF: 2.4GHz ISM
• 2.4G Protocol: ANT
• Antenna: Single antenna
• Input Power: Lipo (2S)/NiMH (5~7Cell)
• BEC Output: 6V/1A
• Continuous/Peak Current: 10A/50A
• Data Output: PWM
• Temperature Range: -10℃ —+60℃
• Humidity Limit: 20%~95%
• WaterProof: PPX4
• Online Update: No
• Dimensions: 33mm*30mm*12mm
• Weight: About 11g
• Certification: CE, FCC ID: N4ZR4A10
Overview
[1] CH1
[2] CH3
[3] CH4
[4] Left-turn light port
[5] Head light port
[6] Right-turn light port
[7] Head light port
[8] Fog light port
[9] Fog light port
[10] Antenna
[11] Power switch
[12] Battery line "+"
[13] Battery line "-"
[14] Motor port "+"
[15] Motor port "-"
[16] Stickers
[17] LED
[18] Left-turn light port
[19] Right-turn light port
[20] Reversing light port
[21] Brake light port
[22] Taillight port
[23] Signal pin
[24] Power "+"
[25] Power "-"
Specifications
