Horizontal stabilizer installation
4.Secure the wings on the fuselage using the included screws
as shown.
5.Lock up the fasteners of supporting bar on main wing as
shown.
1.Secure the horizontal stabilizer using included screws as
shown.
5
Model assembly
EN
HKM3.0*10
KA2.0*8
