1.Hook the tail struts to horizontal stabilizer and vertical
stabilizer as shown.
7
Model assembly
Tail strut installation
Antenna installation
Propeller installation
1.Insert the antenna as shown.
1.Assemble the propeller as shown.
a
b
c
