HIGH PERFORMANCE BUTTERFLY VALVE
FIGURE HPA
8
Item Description
Body
Disc
Seat (Soft)
Seat (Fire Safe)
Stem (Soft Seat)
Stem (Fire Seat)
Seat Retaining Ring
Disc Spacer
Bearing (Soft Seat)
Bearing (Fire Safe)
Wedge Pin
Retainer Screw
Packing Spacer
Item Description
Gland Packing (Soft Seat)
Gland Packing (Fire Safe)
Stem Retainer
Gland Flange
Stud
Belleville Spring
Hex Nut
Cover Gasket (Soft Seat)
Cover Gasket (Fire Safe)
Bottom Cover
Punch Washer
Hex Hd Screw
Seat Gasket (Fire Safe)
7. EXPLODED VIEW
A: 2"–12" (Lug/Wafer)
