Focal Elite User Manual

10
Fs 535Hz
Vas 0.03 liters
Qts 0.37
Qes 0.5
Qms 1.4
Re 5.8Ω
Sd 8 cm
2
Cas 2.38E-08m
5
/N
Mas 84.1kg/m
4
Ras 892582Ω.ac
Cms 367µm/N
Mms 0.24 g
Rms 0.57 kg/s
Ces 25.6mF
Les 3.44mH
Res 16.24Ω
BI 3.06N/A
SPL 92dB/W/m
Nominal power 50W (with filtering)
Maximum power 200W (with filtering)
Sensitivity (2,83V/1m) 93dB
Cone Be
Surround Poron
Nom. impedance 6Ω
DC resistance 5.8Ω
VC diameter 20 mm 0
13/16
"
VC height 1.4 mm 0
1/16
"
Former Aluminium
Layers 2
Wire Copper
Inductance -
Xmax ± 0.1mm
Magnet d x h 38 mm x 35 mm 1
1/2
" x 1
3/8
"
Magnet weight 190 g 0.42lbs
Flux density -
Gap height 1.5 mm 0
1/16
"
Net weight 300 g 0.66lbs
ELITE  UTOPIA BE ULTIMA
User manual
Tweeters
Technical specifications Parameters
