ELITE UTOPIA BE ULTIMA
User manual
Installing the tweeters
Choosing the right location
Ultima tweeters have been designed for surface-mounting or flush-mounting (recommended). Choosing the best
location, mounting method and orientation of the tweeters is extremely important as this will considerably influence
the rendering of the treble, the stability of the stereo image and the staging. Ideally, you should find the best position
so that the left and right tweeters are approximately the same distance away from the listener, oriented towards
the ears of the listener and without any obstacles between the two. You will need to compare the results in various
positions before deciding on the final position. The tweeters must be situated in front of the listening position,
preferably on either extremity of the dashboard (fig. 1, A), or even better, on the A pillar (fig. 1, B).
Flush mount (recommended)
For the best results (for a more linear response and better control of the directivity), a flush mount is recommended
for the tweeters. Route the tweeter wires through the mount, and screw the tweeter into place using the three screws
provided. Check there’s enough depth for the tweeter mount before screwing into place.
• Fig. 1
Sealed volume: 0.3L (0.01 cu.ft)
When manipulating and installing the Ultima tweeters, keep the grilles on to prevent damage in case your
tools are attracted towards the dome due to force of the magnet.
