FPS 1500 FPS 2160 FPS 2300RX FPS 4160 FPS 3000
RMS power - 14.4V
4Ω - THD+N < 1% (CEA 2006)
1 x 325W 2 x 105W 2 x 155W 4 x 120W 590 W
RMS power - 14.4V
2Ω - THD+N < 1%
1 x 550W 2 x 180W 2 x 265W 4 x 200W 1000 W
RMS power - 14.4V
1Ω - THD+N < 1%
1 x 800W - 2 x 430W - 1500 W
RMS power in bridged mode - 14.4V
4Ω - THD+N < 1%
- 1 x 360W 1 x 530W 2 x 380W -
RMS power in bridged mode - 14.4V
2Ω - THD+N < 1%
- - 1x 750W - -
Frequency response (-1dB)
in direct mode
10Hz - 2.5kHz 10Hz - 52kHz 10Hz-25kHz 10Hz - 52kHz
(channels 1-2)
10 Hz - 2.5 kHz
Signal/noise ratio (@ CEA power)
87dBA 92dBA 89dBA 92dBA 93dBA
Distortion into 4 Ohms @ 1kHz
(with 22kHz low-pass)
-
< 0.05%
between 10 and
95W
< 0.04%
between 5 and
110W
< 0.05%
between 5 and
110W
-
Distortion into 4 Ohms @ 100Hz
(with 22kHz low-pass)
< 0.15%
between 5 and
270W
- - -
< 0.2% from
3W to 400W
Crosstalk (@ 1kHz - 10V - 4 Ohms)
- > 64dB > 70dB > 68dB -
Damping factor into
4 Ω at 100Hz
220 250 250 250 300
Input impedance
35kΩ 13kΩ 13kΩ 13kΩ 47kΩ
Input sensitivity
0.2V - 5.2V 0.2V - 5.2V 0.2V - 4.8V 0.2V - 5.2V 0.2V - 4.6V
High-pass crossover
-
50Hz - 500Hz
500Hz - 5kHz-
50Hz - 500Hz
500Hz - 5kHz
50Hz - 500Hz
500Hz - 5kHz
-
Low-pass crossover
50Hz - 500Hz
50Hz - 500Hz
500Hz - 5kHz
50Hz - 500Hz
500Hz - 5kHz
50Hz - 500Hz
500Hz - 5kHz
50 Hz - 500 Hz
Bandpass crossover
-
50Hz - 500Hz
500Hz - 5kHz
50Hz - 500Hz
500Hz - 5kHz
50Hz - 500Hz
500Hz - 5kHz
-
Subsonic crossover
Variable from
20 to 50Hz
(24dB/oct.)
released
- - -
Variable from
20 to 50 Hz (24
dB/oct.) with
bypass
Direct mode
Yes Yes Yes Yes Yes
Bass boost level
0/+9dB linear - 0/+9dB linear - 0/+9 dB linear
